Citronic Ceq215 2 X 15-band Graphic Eq

Citronic Ceq215 - Ceq215 2 X 15-band Graphic Eq

The CEQ215 is a 19" rack mounted dual 15-band graphic equaliser, which allows the adjustment of labelled frequencies via the individual cut/boost faders. Up to 12dB of cut or boost for frequencies ranging from 25Hz to 16kHz for accurate audio spectrum control.

Features

• 2 x 15-band 2/3 octave ISO spacing
• RF filtered servo-balanced inputs
• Constant Q each band
• Bypass switch for EQ comparison
• Low-cut switch each channel
• Gain control each channel
• LED VU meters
• 19" rackmount 1U

Technical Specifications

• Power supply : 115/230Vac, 50/60Hz (IEC)
• Frequency response : 20Hz-20kHz
• Input impedance : balanced : 40k Ohms
• Input impedance : unbalanced : 20k Ohms
• Output impedance : bal/unbal : 330 Ohms
• Channel separation : >50dB
• Signal to noise ratio : >102dB
• THD : 0.005%
• Dimensions : 482 x 44 x 138mm
• Weight : 2.0kg
