Mercury Cat6 U/utp Network Cable 305m Green

More Views

Mercury Cat6 U/utp Network Cable 305m Green
Excl. Vat: £81.18 Incl. Vat: £97.42

Availability: In stock

Cat6 U/UTP Network Cable 305m Green 808.036UK by mercury

Description

Details

Mercury - Cat6 U/utp Network Cable 305m Green

Cat6 oxygen free copper twisted pair data cable supplied in dispensing box and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications.

Features

Oxygen free solid copper conductor
Supplied in an easy-pull dispensing box and marked at 1m intervals
Passes Cat6 fluke test 100m at 250MHz
Complies to TIA/EIA-568 Cat6 standard
HDBaseT Compliant

Technical Specifications

Strands : 8 x 1/0.54mmDia +/-2%
Conductor CSA : 8 x 0.229mm2
Cable : diameter : 5.8mmDia
Insulation : HDPE 0.195mm thickness
Sheath : PVC 0.55mm thickness
Capacitance : 5.2nF/100m
DC resistance @ 20DegC : <9.5 ohms/100m
Impedance (1 to 250MHz) : 100+/-15 ohms
Return loss : >17.3dB @100m
Attenuation : <32.8dB @100m
NEXT : >38.3dB
PSNEXT : >36.3dB
ELFEXT : >19.8dB
PSELFEXT : >16.8dB
Phase delay : <570ns
Conductor : Solid OFC
Cable colour : Green
Length : 305+/-1.5m
Weight : 12.7kg
Cable colour : Green
Length : 305+/-1.5m
Weight : 12.7kg

Additional Information

Additional Information

SKU 808.036UK
Barcode 5015972201985
Manufacturer Mercury
Manfacturer Code 808.036UK
Series N/A
