Qtx Lm41 4 Mono Channel Line Level & Instrument Mixer

More Views

Qtx Lm41 4 Mono Channel Line Level & Instrument Mixer
Excl. Vat: £18.11 Incl. Vat: £21.73

Availability: In stock

4 Mono Channel Line Level & Instrument Mixer 170.204UK by qtx

Description

Details

Qtx Lm41 - 4 Mono Channel Line Level & Instrument Mixer

Compact mixers with high impedance jack inputs Can be used for auxiliary line level or instruments, mixing to a master jack output. Available as either 4 mono or 4 stereo version with separate volume controls for each input and master output. Powered by 1 x 9V battery or optional 12Vdc adaptor

Features

Available in mono or stereo versions
Optional 12Vdc power input
Supplied with 9V battery

Technical Specifications

Battery : 9V battery (PP3 supplied)
Power adaptor : 12Vdc, 200mA (optional)
Output level : +4dB (+8dB max.)
Input impedance : 20k Ohms
Output impedance : 600 Ohms
Dimensions : 150 x 108 x 64mm
Inputs : 4 x 6.3mm jack
Outputs : 1 x 6.3mm jack
Weight : 533g (no battery)

Additional Information

Additional Information

SKU 170.204UK
Barcode 5015972185377
Manufacturer QTX
Manfacturer Code LM41
