Qtx Qx15a Active Speaker Cabinet

Qtx Qx15a - Qx15a Active Speaker Cabinet

Active PA speaker units in a contemporary styled moulded ABS cabinet with integral carry handle and a constant directivity horn. The built-in mixer amplifier section delivers high output to the driver units to develop high SPLs.

Features

• Built-in amplifier with mixer section
• Lightweight ported cabinet
• Titanium compression driver
• 35mm Dia internal top hat
• Mic/line inputs with volume controls
• Tone controls

Technical Specifications

• Power supply : 230Vac, 50Hz (IEC)
• THD : 0.1%
• SNR : 87dB
• Dispersion : 90Deg x 60Deg (H x V)
• Impedance : 4 Ohms
• HF driver : 50mm Ti compression driver
• SPL @ 1W/1m : 103dB
• Crossover frequency : 3.0kHz
• Max. SPL : 129dB
• Power rms : 250W
• Power max. : 500W
• LF driver : 380mm (15")
• LF driver : coil size : 65mmDia
• HF driver : coil size : 35mmDia
• Frequency response : 40Hz - 20kHz
• Dimensions : 420 x 675 x 370mm
• Weight : 17.8kg
• Inputs : Mic (combo), Line (RCA)
