Citronic Csm-6 Mixer With Usb / Bluetooth Player
CSM-6 Mixer with USB / Bluetooth Player 170.872UK by citronic
Citronic Csm-6 - Csm-6 Mixer With Usb / Bluetooth Player
Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls and mono channels also have Effects level to vary the amount of internal digital delay effect added for vocals or instruments. An internal player/recorder with backlit display can accept a USB memory stick containing compressed audio files in various formats or alternatively connect to a smart phone via BT wireless link. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.
Features
- Integral USB multi-format audio player
- BT wireless connectivity
- Supplied with DC power adaptor
- Built in record function
- Digital delay effect for vocals or instruments
- Individually switchable +48V phantom power
Technical Specifications
- Power supply : 5Vdc 1A (adaptor included)
- Output : Left + Right balanced XLR
- Phantom power : +48V individually switchable (XLR inputs only)
- Audio format : USB playback mp3, wma, ape, flac / record mp3 (48kHz 128kB/s)
- Bluetooth version : 2.1 + EDR
- Power consumption max. : 5W
- Max. output level : 3Vrms
- Dynamic range : 102dB
- Frequency response : 20Hz - 20kHz (+/-0.5B)
- THD +N : <0.03% @ 1kHz
- Crosstalk : stereo : 92dB
- Gain : -14 to +40dB
- EQ: low : +/-15dB @ 80Hz
- EQ: high : +/-15dB @ 12kHz
- Audio source : Internal USB player/recorder & BT receiver
- Input impedance : mic : 2k Ohms
- Input impedance : instrument : 1M Ohms
- Input impedance : line : 20k Ohms
- Output impedance : 120 Ohms
- Dimensions : 220 x 165 x 66mm
- Inputs : 4 x combo XLR/jack + stereo jack
- Weight : 1.17kg
Brand | Citronic |
---|---|
Barcode | 5015972207109 |
Manfacturer Code | CSM-6 |
