PA Power Amplifier 2 X 240w, Qtx Q480

Qtx Q480 - Q480 Power Amplifier 2 X 240w

Stereo workhorse power amplifiers with multiple input and output connection options. Designed for accurate and reliable service for venues, DJs and performers.

Features

• 6.3mm jack or RCA inputs
• SPK, 6.3mm jack or 4mm post outputs
• Fan cooled
• 19" rack-mountable (2U)

Technical Specifications

• Power supply : 230Vac, 50Hz (IEC)
• Frequency response : 20Hz - 20kHz
• Input connectors : 6.3mm jack, RCA (L+R)
• Input sensitivity : 775mV, 10k Ohms
• Output connectors : 6.3mm jack, SPK, 4mm binding posts (L+R)
• S/N ratio : >98dB
• THD : <0.5%
• Fuse rating : T5A (240V) / T10A (110V)
• Power max. : 4 Ohms : 2 x 240W
• Power rms : 4 Ohms : 2 x 120W
• Power rms : 8 Ohms : 2 x 80W
• Dimensions : 482 x 300 x 88mm (2U)
• Weight : 6.45kg
